Airtac TACE Guided Compact Cylinder TACE12X45
The AirTAC Airtac TACE Guided Compact Cylinder TACE12X45 is a genuine double acting, non-rotating ISO 21287 compact air cylinder with a Ø12mm bore and 45mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ12 mm
- Stroke45 mm
- Port sizeM5×0.8
- Acting typeDouble acting, non-rotating
- Rod threadM3×0.5
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACE Guided Compact Cylinder TACE12X45
The AirTAC TACE12X45 is a double acting, non-rotating compact cylinder built to ISO 21287: a 12 mm bore with a 45 mm stroke, a hard-anodized aluminium body and an S45C hard-chrome plated 6 mm rod. Twin guide rods on a yoke stop the tooling rotating and carry side load, so a small gripper or plate stays square without any external guide. At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa those figures rise to 79.2 N and 59.4 N, with a theoretical maximum of 11.5 kgf at 1.0 MPa.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it drops into tight jigs, guarding and bench fixtures a full-length cylinder cannot reach. For sizing, plan on roughly 33.9 N of usable push at 0.5 MPa (about 60% of the rating), which lifts about 2.9 kg vertically with a 2:1 margin. Air supply is a single M5x0.8 port, the rod end carries a female M3x0.5 thread, and the optional -S magnet allows CMSE / DMSE switches to report position - without -S there is no magnet fitted. Fixed TPU bumpers at both ends absorb end-of-stroke shock across a 30-500 mm/s speed range.
Airtac TACE Guided Compact Cylinder TACE12X45 Technical Specifications
| Model | Airtac TACE Guided Compact Cylinder TACE12X45 |
|---|---|
| Series | TACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø12 mm |
| Stroke | 45 mm |
| Acting type | Double acting, non-rotating |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø12mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 57 N | 42 N |
| 0.7 MPa | 79 N | 59 N |
| Max (@1.0 MPa) | 12 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin. Twin guide rods stop the tooling rotating.
Model Code: Airtac TACE Guided Compact Cylinder TACE12X45
| TACE | ISO 21287 compact cylinder (non-rotating (twin-guide yoke)). |
|---|---|
| 12 | Bore size in mm. |
| ×45 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACE Guided Compact Cylinder TACE12X45 Is Used
SMT feeder pusher
Slides small PCB edge carriers or component reels into pick position on a placement machine, where the 45 mm stroke and twin-guide yoke keep the pusher square in a narrow lane.
Diagnostic vial ejector
Ejects 10-12 mm sample vials from a lab analyzer nest; the 56.5 N push at 0.5 MPa is enough for light plastic tubes and the compact body fits inside the instrument deck.
Cosmetic bottle lane divider
Nudges lip balm or serum bottles between conveyor lanes on a small packaging line, with the optional -S magnet and a CMSE switch confirming the divider is fully home.
Is the Airtac TACE Guided Compact Cylinder TACE12X45 the Right Cylinder?
Bore 12 is the smallest in the TACE range, so check the load before committing: 56.5 N push at 0.5 MPa suits light clamping and small part transfer, while bore 16 gives 100.5 N push at the same pressure if the load is marginal. Remember the piston drifts when air is lost - it never locks or holds a load - so add a rod lock or pilot check valve where a raised part must stay put. Mounting choices are FB flange, CA/CB clevis, CR and FTC; order the -S code only if CMSE / DMSE position switches are needed.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACE Guided Compact Cylinder TACE12X45 FAQ
At 0.5 MPa the 12 mm bore pushes 56.5 N and pulls 42.4 N; at 0.7 MPa it pushes 79.2 N and pulls 59.4 N. The theoretical maximum is 11.5 kgf at 1.0 MPa. Operating pressure spans 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof rating, running on air filtered to 40 um.
It is an ISO 21287 compact cylinder whose short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, with fixed TPU bumpers at both ends absorbing end-of-stroke energy. Mounting options include FB flange, CA/CB clevis, CR and FTC. Add the optional -S code to enable CMSE or DMSE switches; without -S there is no magnet, so no sensor can be mounted.
