Airtac TACE Guided Compact Cylinder TACE12X5
The AirTAC Airtac TACE Guided Compact Cylinder TACE12X5 is a genuine double acting, non-rotating ISO 21287 compact air cylinder with a Ø12mm bore and 5mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder. Twin guide rods keep the tooling from rotating.
- BoreØ12 mm
- Stroke5 mm
- Port sizeM5×0.8
- Acting typeDouble acting, non-rotating
- Rod threadM3×0.5
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac TACE Guided Compact Cylinder TACE12X5
The TACE12X5 is a double acting, non-rotating compact cylinder built to ISO 21287: a 12 mm bore with a short 5 mm stroke on a hard-anodized aluminium body. Twin guide rods on a yoke stop the tooling rotating, so a small gripper or plate stays square without an external guide. At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa that rises to 79.2 N push and 59.4 N pull, with a theoretical peak of 11.5 kgf at 1.0 MPa.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into tight fixtures and guarding where a full-length cylinder will not. Plan on roughly 34 N of usable push at 0.5 MPa, about 60% of the rating, which lifts about 2.9 kg vertically with a 2:1 margin. The -S magnet is optional: without it no CMSE or DMSE switch can be fitted. A fixed TPU bumper absorbs end-of-stroke energy at both ends.
Airtac TACE Guided Compact Cylinder TACE12X5 Technical Specifications
| Model | Airtac TACE Guided Compact Cylinder TACE12X5 |
|---|---|
| Series | TACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø12 mm |
| Stroke | 5 mm |
| Acting type | Double acting, non-rotating |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating; guide rods: stainless steel (Ø12-40) / S45C (larger). Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø12mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 57 N | 42 N |
| 0.7 MPa | 79 N | 59 N |
| Max (@1.0 MPa) | 12 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin. Twin guide rods stop the tooling rotating.
Model Code: Airtac TACE Guided Compact Cylinder TACE12X5
| TACE | ISO 21287 compact cylinder (non-rotating (twin-guide yoke)). |
|---|---|
| 12 | Bore size in mm. |
| ×5 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac TACE Guided Compact Cylinder TACE12X5 Is Used
Connector pin ejection
A 5 mm stroke is ideal for nudging a finished USB or sensor connector off its nest in an electronics assembly machine; the twin-guide yoke keeps the push square on the part.
Microplate handling
With about 2.9 kg of vertical lift capacity at a 2:1 margin, the TACE12X5 can raise small vials or a loaded sample tray in a laboratory dispensing station.
PCB press-check fixture
In a solder or test jig, the 56.5 N push at 0.5 MPa presses a small circuit board onto contact pins, and the non-rotating rods keep the head aligned.
Is the Airtac TACE Guided Compact Cylinder TACE12X5 the Right Cylinder?
The 5 mm stroke sits well inside the 50 mm maximum standard stroke for this 12 mm bore, so no made-to-order length is needed. If 56.5 N of push at 0.5 MPa is marginal for the job, step up to the 16 mm bore, which delivers 100.5 N at the same pressure. The piston drifts when air is lost, so add a rod lock or pilot check valve wherever a held load matters. Mount with FB, CA, CB, CR or FTC, and order the -S code if CMSE or DMSE switch sensing is required.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac TACE Guided Compact Cylinder TACE12X5 FAQ
At 0.5 MPa the TACE12X5 pushes 56.5 N and pulls 42.4 N. At 0.7 MPa push rises to 79.2 N and pull to 59.4 N. The theoretical maximum is 11.5 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa (22-145 psi), speed is 30-500 mm/s, and the air must be filtered to 40 um.
FB flange, CA/CB clevis, CR and FTC mounts are available; the rod end carries a female M3x0.5 thread and the air port is M5x0.8. Position sensing requires the optional -S magnet, which lets CMSE or DMSE switches read the piston; without -S there is no magnet. The body is hard-anodized aluminium with an S45C hard-chrome rod, and fixed TPU bumpers absorb end-of-stroke energy at both ends.
