Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1003
$4.62
Regular price
$12.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABC1003
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABC1003 Push-in Fitting Specifications
- Model: X-ABC1003
- Type: Straight terminal with locknut (one-touch connector)
- Thread standard: M5×0.8 external thread (BSPP/NPT optional)
- Material: Nickel-plated brass body + PPS resin sleeve
- Tube compatibility: Ø4mm (5/32") OD pneumatic tubing
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (continuous use)
- Seal material: FKM fluoroelastomer (-15℃ to 150℃ peak)
- Vibration resistance: ≤10 Hz / 1.5mm amplitude
- Weight: 8.2g ±0.3g
- Dimensions: 19.5mm(L) × 12mm(W) × 12mm(H)
- Certifications: RoHS compliant, REACH SVHC-free
High-density sealing connector with 360° rotatable sleeve for flexible tubing alignment. Features triple-locking mechanism (thread + O-ring + collet) to prevent air leaks under pulsation. Compatible with air, inert gases, and vacuum systems. Rated for 500,000+ insertion cycles.
Typical Applications:
- Modular pneumatic manifolds in assembly robots
- Tool-free maintenance connections for CNC machines
- Compact sensor air supply lines
- Vacuum pick-and-place systems
- Medical device pneumatic controls
Installation protocol:
Insert tubing until audible click (minimum 15mm insertion depth).
Use 0.8-1.2 N·m torque for locknut. Apply thread sealant only on male threads,
avoiding contact with O-ring surfaces.
| Property | Property Value |
|---|---|
| sku | X-ABC1003 |
