Description
AirTAC X-ABC1003A Fitting-Locknut Straight Terminal Specifications
- Model: X-ABC1003A
- Type: Straight thread-locknut terminal (male thread)
- Thread standard: Metric (M5×0.8)
- Material: Nickel-plated brass body, PPS resin locknut
- Seal type: Integrated O-ring (NBR)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Tube compatibility: Φ4mm PU/Nylon tubing
- Torque rating: 0.8–1.2 N·m (locknut tightening)
- Weight: 6.8g ±0.5g
- Dimensions: 15.2mm(L) × 10.5mm(W) × 10.5mm(H)
- Certification: RoHS compliant
- Surface resistance: ≥100MΩ (500V DC)
High-density engineered terminal fitting featuring vibration-resistant locknut design with color-coded collar identification. The precision-machined conical seat ensures leak-free connections even under thermal cycling conditions. Optimized for 3-5mm wall thickness mounting panels.
Typical Applications:
- Modular pneumatic manifold assemblies
- CNC machine tool air circuits
- Robotic end-effector pneumatic routing
- Semiconductor fab equipment
- Inline pressure sensor installations
Installation protocol:
Hand-tighten locknut until 1.5 threads remain visible, then apply calibrated torque.
Always use backup wrench on hex body during final tightening to prevent tube torsion.
| Property | Property Value |
|---|---|
| sku | X-ABC1003A |
