Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1004
AirTAC X-ABC Series Straight Through Terminal with Locknut (X-ABC1004)
- Model: X-ABC1004
- Type: Straight-through push-to-connect terminal with locknut
- Body material: PA66+GF25% (UL94 V-2 flame retardant)
- Seal material: NBR (Nitrile rubber)
- Applicable tubing OD: Ø4mm (1/8")
- Thread specification: M5×0.8 internal thread
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to +80℃ (-4°F to +176°F)
- Vibration resistance: 1.5mm amplitude at 10-55Hz
- IP rating: IP40 (dust protected)
- Installation torque: 0.8-1.2 N·m
- Weight: 12g ±0.5g
- Dimensions: 15mm(L) × 10mm(W) × 10mm(H)
High-density polymer terminal with integrated locknut design for secure pneumatic connections. Features color-coded collar (standard blue) for quick identification and a 360° rotatable fitting body. The dual-seal structure prevents air leakage under pulsation conditions. Compatible with PU, NY, and PE tubing.
- Modular pneumatic circuit assembly in industrial robots
- Branch line connections for conveyor sorting systems
- Compact control valve manifolds in packaging machinery
- Laboratory pneumatic instrument clusters
- Mobile equipment air supply junctions
Installation note:
Always insert tubing perpendicularly until it bottoms out. For maintenance,
depress the collet fully before tube removal. Use backup wrench on hex base
during locknut tightening to prevent body rotation.
Avoid overtightening - exceeding 1.5N·m
may deform polymer threads. Not recommended for hydrocarbon-based fluids.
| Property | Property Value |
|---|---|
| sku | X-ABC1004 |
