Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1004A
AirTAC X-ABC Series Connector - Locknut Straight Terminal X-ABC1004A Specifications
- Model: X-ABC1004A
- Type: Locknut straight terminal (push-to-connect)
- Thread specification: M5×0.8 (male thread)
- Material: Nickel-plated brass body + PPS resin collar
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -5℃ to 80℃
- Tube compatibility: Φ4mm (1/8") PU/Nylon tubing
- Seal type: Double O-ring (NBR material)
- Vibration resistance: ≤10Hz (amplitude ≤1mm)
- Weight: 12.5g ±0.3g
- Dimensions: 20mm(L) × 14mm(W) × 14mm(H)
- IP rating: IP40 (dust protected)
- Reusable cycles: ≥50 times
High-density compression fitting with integrated locknut design, featuring tool-free tube insertion and 360° rotatable connection. The corrosion-resistant nickel plating ensures durability in humid environments, while the PPS collar provides chemical resistance against oils and weak acids.
- Pneumatic valve terminal blocks
- Air compressor distribution lines
- CNC machine tool pneumatic circuits
- Automated packaging line actuators
- Laboratory instrument air supply
Installation note:
Hand-tighten locknut clockwise until resistance is felt (recommended torque: 0.8-1.2Nm).
Always insert tubes perpendicularly until they bottom out. Apply silicone-free lubricant
when reusing connections.
| Property | Property Value |
|---|---|
| sku | X-ABC1004A |
