Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1202
AirTAC X-ABC Locknut Straight Terminal X-ABC1202 Technical Details
- Model: X-ABC1202
- Type: Threaded locknut straight terminal (male to female)
- Thread standard: Metric (M5×0.8) & PT1/8 dual markings
- Material: Brass with nickel plating (surface hardness ≥HV200)
- Seal material: NBR (Nitrile) O-ring
- Pressure rating: 0.05–1.5 MPa
- Temperature range: -5℃ to 80℃
- Thread engagement length: 7.5±0.3mm
- Hex size: 12mm wrench flat
- Weight: 8.2g ±0.5g
- Dimensions: 19.5mm(L) × 12mm(Hex W) × 12mm(Hex H)
- Surface roughness: Ra ≤3.2μm
- Certification: RoHS compliant
Dual-threaded pneumatic connector with integrated locknut for secure tubing connections in dynamic systems. Features anti-vibration teeth (3 crisscross grooves) on the nylon locknut and 360° rotatable fitting body. Rated for 500,000+ insertion cycles with <1% leakage at 0.5MPa pressure.
- Modular pneumatic manifolds requiring frequent disassembly
- Robotic arm end-effector tooling with vibration resistance
- ISO-2 modular valve terminal block integration
- Medical equipment requiring hygienic seal surfaces
- Mobile hydraulic/pneumatic hybrid systems
Mounting protocol:
Hand-tighten until resistance is felt, then apply 0.8-1.2N·m torque with wrench.
Always use thread seal tape on male threads. Compatible with OD 4mm/6mm/8mm tubing.
| Property | Property Value |
|---|---|
| sku | X-ABC1202 |
