Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1204
AirTAC X-ABC1204 Connector-Locknut Straight Terminal Specifications
- Model: X-ABC1204
- Type: Straight through terminal with locknut
- Body material: Nickel-plated brass (corrosion resistant)
- Seal material: NBR (Nitrile) rubber
- Thread standards: Dual-standard compatible (BSPP-G1/8 & NPT1/8)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Tube OD compatibility: 4mm (soft nylon/polyurethane tubes)
- Thread engagement depth: 8±0.5mm
- Torque specification: 1.2-1.5 N·m during installation
- Weight: 28g ±2g
- Dimensions: 32mm(L) × 16mm(W) × 16mm(H)
- Certification: RoHS compliant
Precision-engineered pneumatic terminal featuring anti-vibration locknut design with 360° rotatable fitting body. The dual-seal structure combines metal-to-metal sealing (30° cone seat) with elastic NBR sealing for leak-proof performance in dynamic applications. Nickel plating provides enhanced wear resistance against repeated tube insertions.
- Modular pneumatic manifolds requiring compact connections
- Robotic arm end effector air supply lines
- Medical equipment pneumatic circuits demanding vibration resistance
- Packaging machinery with frequent maintenance cycles
- Laboratory automation gas distribution systems
Installation protocol:
(1) Hand-tighten locknut before final torque application
(2) Use tube insertion depth gauge (4mm mark) for proper seating
(3) Perform pressure test at 1.25× working pressure after installation
| Property | Property Value |
|---|---|
| sku | X-ABC1204 |
