Airtac X-ABC Connector - Locknut Straight Terminal X-ABC1204A
AirTAC X-ABC1204A Bulkhead Union Connector with Locknut Specifications
- Model: X-ABC1204A
- Type: Through-type terminal connector with integrated locknut
- Material: Brass (Nickel-plated) body / NBR sealing ring
- Tube OD compatibility: 12mm (metric) / 1/2" (imperial optional)
- Thread specification: M12×1.5 male thread
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Surface treatment: Electrolytic polishing anti-corrosion coating
- Vibration resistance: ≤5Hz @ 2.5mm amplitude
- Weight: Approx. 42g (including packaging)
- Dimensions: 28mm (L) × 16mm (W) × 16mm (H)
- Certification: ISO 6150-B standard compliant
- Color coding: Silver body with blue sealing ring (standard)
Robust bulkhead connector featuring dual-seal technology with primary O-ring and secondary metal-to-metal contact. The integrated hex locknut enables single-wrench installation through panels (1-3mm thickness supported). Internal flow path optimized for minimal pressure drop (ΔP<0.02MPa @ 5L/min).
- Pneumatic control cabinet panel mounting
- Modular assembly in automation machinery
- Coolant line connections in CNC equipment
- Vacuum system interfaces for packaging lines
- Medical gas distribution panels
Installation protocol:
Apply 2-3 N·m torque during locknut tightening. Use backup wrench on body flats
to prevent rotation. Perform pressure test at 1.5× operating pressure after installation.
- X-ABC12 series dust caps (sold separately)
- AT-RK12 thread reinforcement kit for soft materials
- PTFE tape (0.1mm thickness recommended)
| Property | Property Value |
|---|---|
| sku | X-ABC1204A |
