Airtac X-ABC Connector - Locknut Straight Terminal X-ABC402
AirTAC X-ABC402 Threaded Connector-Locknut Straight Terminal Specifications
- Model: X-ABC402
- Type: Straight-through terminal with integrated locknut
- Material: Brass (nickel-plated)
- Thread Standard: BSPP (G1/8) / NPT1/8 optional
- Seal Material: NBR (Nitrile) rubber
- Max Working Pressure: 1.5 MPa (217 psi)
- Pressure Range: 0.3-1.5 MPa
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Thread Engagement: ≥3 full turns
- Weight: 48g ±2g
- Dimensions: 50mm(L) × 25mm(W) × 25mm(H)
- Surface Roughness: Ra ≤3.2μm
- Leakage Rate: ≤0.1 NL/min @ 0.5 MPa
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Protection Rating: IP40
High-density forged brass terminal with precision-machined threads, designed for secure pneumatic line connections. Features dual sealing structure with O-ring and metal-to-metal contact. Nickel plating provides corrosion resistance in humid environments. Compatible with PU, nylon, and rubber tubing (4mm OD).
- Pneumatic valve manifold assemblies
- Air preparation unit (FRL) connections
- Industrial robot end-effector air supply
- CNC machine tool pneumatic circuits
- Packaging machine actuator lines
- Laboratory instrumentation gas lines
Installation protocol:
Hand-tighten locknut first, then apply 0.8-1.2 N·m torque using a crowfoot wrench.
Always install O-ring with silicone grease (ASG-55 recommended).
Avoid cross-threading by aligning connector axis before rotation.
| Property | Property Value |
|---|---|
| sku | X-ABC402 |
