Airtac X-ABC Connector - Locknut Straight Terminal X-ABC603
AirTAC X-ABC603 Female Threaded Straight Terminal Specifications
- Model: X-ABC603
- Type: Straight-through terminal with female threaded locknut
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile) rubber
- Thread specification: M5×0.8 female thread (both ends)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (with silicone seals optional up to 120℃)
- Flow coefficient (Cv): 0.15
- Port-to-port length: 15.8±0.5mm
- Hex size: 10mm wrench flat
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Weight: 18±2g
- Dimensions: 15.8mm(L) × 10mm(W) × 10mm(H)
- Protection rating: IP54 (standard sealing)
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
A compact pneumatic terminal connector featuring dual female threads with integrated locking nut design. The nickel-plated construction ensures corrosion resistance in humid environments, while the precision-machined internal channels minimize pressure drop. The tapered seat design provides bubble-tight sealing at 1.5x rated pressure. Compatible with PU/Nylon tubing (ID 3.2mm).
- Modular pneumatic manifold interconnections
- Robotic end effector air supply lines
- Semiconductor wafer handling equipment
- Medical device pneumatic control systems
- Food processing machine air knife connections
- Apply 2-3 wraps of PTFE tape on male threads (Do NOT use pipe dope)
- Tighten with 10mm open-end wrench - torque limit 1.2N·m
- Maximum angular misalignment tolerance: ±3°
- For vertical downward tube routing, use supporting clamp within 150mm
Compatibility note:
Not recommended for use with phosphate ester-based lubricants.
Use ISO VG32 or equivalent pneumatic oil only.
