Airtac X-ABC Connector - Locknut Straight Terminal X-ABC801
AirTAC X-ABC801 Fitting - Locknut Straight Terminal Specifications
- Model: X-ABC801
- Type: Straight-through terminal with locknut
- Material: Brass (nickel-plated surface)
- Thread Standard: Metric (M5×0.8 thread)
- Operating Pressure: 0-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Seal Material: NBR (Nitrile Rubber) / Optional FKM
- Proof Pressure: 1.5 MPa
- Leakage Rate: ≤3×10⁻⁸ Pa·m³/s (helium test)
- Surface Treatment: Electroplated zinc with chromate finish
- Weight: 12g ±0.5g
- Dimensions: 25mm(L) × 8mm(Ø) × 15mm(Hex)
- Installation Torque: 0.8-1.2 N·m
- Vibration Resistance: 10-2000Hz, 20m/s²
- IP Rating: IP54 (when properly installed)
Precision-engineered straight terminal connector featuring dual-stage sealing with integrated locknut. The hexagonal body design allows tool-assisted tightening while maintaining compact dimensions. Nickel plating provides corrosion resistance in humid environments (salt spray test passed 96hrs).
- Modular pneumatic manifold block terminations
- Sensor/valve port extensions in tight spaces
- Robotic end-effector air supply connections
- Medical device pneumatic circuits
- CNC machine tool pneumatic distribution
Installation protocol:
Apply thread sealant only on male threads (PTFE tape not recommended).
Tighten using 8mm wrench flat while holding locknut with 10mm spanner.
Perform pressure test at 110% working pressure after installation.
