Airtac X-ABC Connector - Locknut Straight Terminal X-ABC801A
AirTAC X-ABC801A Connector-Locknut Straight Terminal Specifications
- Model: X-ABC801A
- Type: One-touch straight terminal with locknut
- Material: Nickel-plated brass body + PPS resin sleeve
- Thread size: M5×0.8 (external) / PT1/8 (internal)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -5℃ to 90℃
- Seal material: Fluororubber (FKM)
- Installation torque: 0.7–1.2 N·m
- Vibration resistance: 10–55 Hz (double amplitude 1.5mm)
- Certification: RoHS compliant
- Weight: 18.5g ±0.3g
- Dimensions: 23mm(L) × 14mm(Dia) × 11mm(Hex)
High-density sealing terminal featuring dual-material construction for leak-proof connections in compact pneumatic systems. The hexagonal base allows tool-assisted tightening, while the color-coded resin sleeve (standard blue) enables quick visual circuit identification. Compatible with OD 4mm polyurethane/nylon tubing.
- Modular pneumatic manifolds requiring space optimization
- Robotic end-effector tooling connections
- CNC machine lubrication line junctions
- Semiconductor manufacturing equipment
- Automated test bench pneumatic routing
Installation protocol:
Apply 1.5 wraps of PTFE tape on male threads before assembly.
Tighten until sleeve clicks (audible feedback) then +¼ turn with wrench.
Maximum angular misalignment tolerance: 3°.
| Property | Property Value |
|---|---|
| sku | X-ABC801A |
