Airtac X-ABC Connector - Locknut Straight Terminal X-ABC803
AirTAC X-ABC803 Push-in Fitting Terminal Specifications
- Model: X-ABC803
- Type: Straight thread-lock nut terminal (one-touch fitting)
- Material: Brass body with PPS resin collar
- Thread standard: M5×0.8 internal thread
- Tube compatibility: Ø4mm (1/8") OD pneumatic tubing
- Temperature range: -20℃ to 80℃
- Pressure range: 0.05–1.5 MPa
- Seal material: NBR (Nitrile) O-ring
- Vibration resistance: ≤10Hz with 1.5mm amplitude
- IP rating: IP40 (dust protected)
- Certifications: RoHS compliant, REACH SVHC-free
- Weight: 18g ±0.5g
- Dimensions: 25mm(L) × 18mm(W) × 18mm(H)
High-density forged brass terminal with tool-free tube insertion, designed for stable connections in compact pneumatic systems. Features anti-vibration locking mechanism and 360° rotatable collar for flexible hose routing. Includes integrated dust cap for port protection during maintenance.
- Modular pneumatic manifolds in factory automation
- Robotic end-effector air supply lines
- Medical device pneumatic control panels
- Food processing machinery (requires optional FDA-grade seals)
- Laboratory analytical instrument gas lines
Installation note:
For optimal sealing, cut tubing ends square (±2° tolerance) and insert fully until
audible click. Release collar before tube removal - requires 2.5kg minimum pull-out force
when properly engaged. Not recommended for hydraulic fluids or aggressive chemicals.
| Property | Property Value |
|---|---|
| sku | X-ABC803 |
