Airtac X-ABC Connector - Locknut Straight Terminal X-ABC803A
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABC803A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABC803A Bulkhead Union Terminal Specifications
- Model: X-ABC803A
- Type: Straight thread terminal with locknut
- Thread standard: Metric (M5×0.8)
- Material: Brass with nickel plating (stainless steel optional)
- Seal material: NBR (Nitrile) rubber
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Tube OD compatibility: Φ4mm, Φ6mm, Φ8mm (multi-size grip)
- Surface roughness: Ra ≤3.2μm
- Torque specification: 1.2-1.5 N·m (installation)
- Weight: 12.5g ±0.3g
- Dimensions: 20mm(L) × 10mm(Dia) × 15mm(Flange width)
- Certification: RoHS compliant
- Package quantity: 50pcs/box (bulk packaging)
Precision-engineered bulkhead fitting featuring triple-seal technology (thread seal, O-ring seal, and tube grip seal) for leak-free pneumatic connections through panels. The 360° rotatable locknut enables tool-free adjustment during maintenance. Compatible with ISO 8434-1 standards.
Typical Applications:
- Modular pneumatic control cabinets
- CNC machine tool pneumatic interfaces
- Food processing equipment with washdown requirements
- Robotic arm end-effector connections
- Compressed air distribution manifolds
- Laboratory instrument gas lines
Installation protocol:
Apply 2-3 drops of pneumatic sealant on male threads before assembly.
Hand-tighten locknut first, then perform 1/4 turn with a torque wrench.
Maximum 3 reuses recommended for critical pressure applications.
Flow performance:
Maintains 95% original flow rate after 10,000 pressure cycles (per ISO 19879 test)
| Property | Property Value |
|---|---|
| sku | X-ABC803A |
