Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1002
AirTAC X-ABL1002 Locknut Elbow Terminal Specifications
- Model: X-ABL1002
- Type: Right-angle terminal with integrated locknut
- Thread specification: PT1/8 (BSPP) female thread
- Material: Engineering plastic (PBT+30%GF)
- Seal material: NBR rubber (optional FKM available)
- Pressure rating: 0.5-1.5 MPa
- Temperature range: -20℃ to 80℃
- Surface finish: Anti-corrosion coating (salt spray test ≥72h)
- Installation torque: 0.7-1.2 N·m (recommended)
- Weight: 18.5g ±0.3g
- Dimensions: 24.5mm(L) × 21mm(W) × 28mm(H)
- Tube compatibility: Ø4mm (1/8") pneumatic tubing
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-molded right-angle connector featuring a captive swivel nut for tool-free installation. The chamfered entry design prevents tubing abrasion during assembly. Rotatable 360° body allows flexible orientation adjustment post-installation. Meets ISO 6150-B standard for pneumatic fittings.
- Space-constrained pneumatic manifolds
- Robotic arm end-effector tooling
- CNC machine tool air curtain systems
- Semiconductor wafer handling equipment
- High-cycle packaging machinery
Installation note:
Hand-tighten until snug, then apply 1/4 turn with wrench. Avoid overtightening -
the integral O-ring requires compression, not extreme pressure.
Lubricate threads when used in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | X-ABL1002 |
