Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1002A
AirTAC X-ABL1002A Locknut Elbow Terminal Specifications
- Model: X-ABL1002A
- Type: Reusable push-to-connect elbow terminal with locknut
- Thread standard: Metric (M5×0.8) & PT1/8 (BSPP) dual markings
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) / FKM (Fluorocarbon) optional
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Tube compatibility: Ø4mm (5/32") OD pneumatic tubing
- Torque specification: 0.8–1.2 N·m (locknut tightening)
- Weight: 12.5g ±0.3g
- Dimensions: 20mm(L) × 15mm(W) × 12mm(H)
- Rotation range: 360° swivel capability
- Certification: RoHS compliant
Precision-engineered right-angle connector featuring a double-sealing structure with dust-resistant O-ring and metal-to-metal primary seal. The unique anti-vibration locknut design prevents loosening in high-cycle applications. Compatible with both soft nylon and polyurethane tubing through its collet grip mechanism.
- Robotic arm pneumatic tool changers
- CNC machine tool clamp circuits
- Semiconductor wafer handling equipment
- Mobile hydraulic control manifolds
- Laboratory analytical instrument gas lines
Installation protocol:
Hand-tighten locknut before final torque application. Rotate fitting body (not the nut) during tube insertion.
Perform pressure test at 1.5× system pressure after installation. Replace O-rings every 50,000 cycles.
