Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1003
AirTAC X-ABL1003 Right Angle Terminal with Locknut Specifications
- Model: X-ABL1003
- Type: Male thread straight-through locknut terminal (90° elbow)
- Thread standard: G1/8 (BSPP parallel thread)
- Material: Brass CW617N with nickel plating
- Seal type: Integrated NBR O-ring (pre-lubricated)
- Pressure range: 0.05–1.5 MPa
- Temperature range: -20℃ to 80℃
- Tube OD compatibility: 6mm (φ6 pneumatic tubing)
- Weight: 28g ±2g
- Dimensions: 25mm(L) × 18mm(W) × 20mm(H)
- Surface roughness: Ra ≤1.6μm (sealing surfaces)
- Torque specification: 10-12 N·m (locknut tightening)
- Vibration resistance: ≤10Hz @ 2.5mm amplitude
- Certification: RoHS compliant
A precision-machined pneumatic terminal featuring anti-vibration locknut design and zero-clearance swivel mechanism. The electro-less nickel plating provides enhanced corrosion resistance in humid environments. Pre-installed EPDM backup ring prevents O-ring extrusion under peak pressure conditions.
- Modular pneumatic manifold end connections
- Robotic arm tooling air supply interfaces
- CNC machine coolant line junctions
- Laboratory analyzer gas sampling systems
- Electric vehicle battery cooling manifolds
Installation protocol:
Use dual wrench technique - hold body with 17mm open-end wrench while tightening locknut with 14mm crowfoot socket. Apply PTFE tape only on male threads (2 wraps max). Perform pressure test at 1.25× operating pressure after assembly.
- Cv value: 0.85
- Effective flow area: 2.1 mm²
- Pressure drop: ≤0.02 MPa @ 500 NL/min
| Property | Property Value |
|---|---|
| sku | X-ABL1003 |
