Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1004
AirTAC X-ABL1004 Locknut Right Angle Terminal Specifications
- Model: X-ABL1004
- Type: 90° elbow terminal with swivel locknut
- Thread standard: PT1/8 (BSPP)
- Material: Brass (nickel-plated body)
- Seal material: NBR + metal retainer
- Max working pressure: 1.5 MPa
- Temperature range: -5℃ to 80℃
- Torque resistance: ≤3 N·m
- Flow rate: 120 NL/min (at 0.5 MPa)
- Weight: 15g ±0.5g
- Dimensions: 25mm(L) × 20mm(W) × 18mm(H)
- Surface roughness: Ra ≤1.6μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered right-angle pneumatic connector featuring dual-stage sealing and anti-vibration locknut. The rotating collar allows 360° orientation adjustment while maintaining leak-proof connection. Zinc-nickel composite coating provides corrosion resistance in humid environments.
- Robotic arm pneumatic tool changers
- CNC machine air blow cleaning systems
- Semiconductor wafer handling equipment
- Mobile hydraulic test bench manifolds
- Packaging machine rotary joint interfaces
Installation protocol:
Hand-tighten locknut before final torque adjustment. Use backup wrench on hex base (8mm AF) during assembly.
Maximum 1/4 turn past finger-tight position. Test with 0.8 MPa air pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-ABL1004 |
