Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1004A
$6.32
Regular price
$13.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABL1004A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABL1004A Lock Nut Elbow Terminal Specifications
- Model: X-ABL1004A
- Type: 90° Elbow Terminal with Lock Nut
- Material: Brass with nickel plating (corrosion-resistant)
- Thread Specification: M5×0.8 internal thread
- Tube Compatibility: 4mm OD polyurethane/nylon tubing
- Max Working Pressure: 1.5 MPa (15 bar)
- Temperature Range: -5℃ to 80℃
- Seal Material: NBR (Nitrile) O-ring
- Installation Torque: 0.25-0.3 N·m (Do NOT exceed 0.5 N·m)
- Weight: 15g ±0.5g
- Dimensions: 20mm(L) × 16mm(W) × 16mm(H)
- Surface Roughness: Ra ≤1.6μm (sealing surfaces)
- Certification: RoHS compliant
Precision-engineered elbow connector with integrated lock nut, designed for leak-free transitions in confined spaces. Features dual-stage sealing with tapered thread engagement and compression ring for vibration resistance. Compatible with pneumatic and low-pressure hydraulic systems.
Typical Applications:
- Compact pneumatic manifolds in robotics
- Sensor mounting brackets requiring right-angle connections
- Medical device gas line interfaces
- Conveyor system emergency stop circuits
- Beverage dispenser valve linkages
Installation protocol:
Hand-tighten until snug, then apply 1/8 turn with wrench. Use thread sealant only on male threads,
never on tube insertion end. Perform pressure test at 1.1x system pressure after installation.
Note: For optimal performance with AirTAC XA/XB series valves.
Not recommended for continuous rotation applications or media containing ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | X-ABL1004A |
