Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1202A
$5.91
Regular price
$13.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABL1202A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABL1202A Lock Nut Elbow Terminal Specifications
- Model: X-ABL1202A
- Type: Right-angle terminal with lock nut
- Material: Brass (nickel-plated)
- Thread specification: M12×1.5
- Applicable tube OD: Φ12mm (polyurethane/nylon)
- Max working pressure: 1.0 MPa
- Pressure range: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Vibration resistance: ≤10 Hz (1.5mm amplitude)
- Protection rating: IP40
- Weight: 48g ±2g
- Dimensions: 30mm(L) × 25mm(W) × 25mm(H)
- Surface roughness: Ra ≤3.2μm
- Torque resistance: 18-22 N·m tightening torque
Precision-engineered 90° pneumatic connector featuring dual-stage sealing (thread & tube interfaces) with anti-vibration lock nut. The nickel plating provides corrosion resistance in humid environments. Optimized flow path reduces pressure drop by 15% compared to standard elbows.
Typical Applications:
- Robotic arm pneumatic tool changers
- CNC machine tool clamping systems
- Automated packaging line actuators
- Semiconductor wafer handling equipment
- Food-grade pneumatic systems (NSF compliant)
Installation protocol:
Hand-tighten until 2-3 threads remain visible, then apply final torque (20N·m max) using a crowfoot wrench.
Always perform pressure test at 1.5× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-ABL1202A |
