Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1203
$6.06
Regular price
$13.56
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-ABL1203
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-ABL1203 Locknut Right-Angle Terminal Specifications
- Model: X-ABL1203
- Type: Right-angle terminal with locknut (male thread)
- Body material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber)
- Thread specification: PT1/8 (BSPP)
- Operating pressure: 0.05–1.5 MPa
- Proof pressure: 2.25 MPa
- Temperature range: -20℃ to 80℃
- Installation torque: 1.5–2 Nm
- Surface treatment: Chromate conversion coating
- Weight: 12g ±0.5g
- Dimensions: 18mm(L) × 18mm(W) × 24mm(H)
- Vibration resistance: ≤49 m/s² (10-1500Hz)
- Compliance: RoHS 2011/65/EU
Precision-engineered right-angle pneumatic connector with 90° flow path optimization. Features anti-vibration locknut design with dual sealing layers (thread seal + face seal). Electroplated finish prevents oxidation in humid environments. Rated for 500,000+ mating cycles.
Typical Applications:
- Space-constrained pneumatic manifolds
- Robotic end-effector tooling
- Medical gas line connections
- Packaging machine actuator interfaces
- Laboratory instrumentation plumbing
Installation protocol:
Apply 1.5 wraps of PTFE tape clockwise on male threads. Hand-tighten first,
then torque to 1.8Nm using a crowfoot wrench. Avoid aligning port direction
against fluid flow arrow.
Compatibility note:
Not suitable for phosphate ester fluids or chlorinated solvents.
Always perform pressure test at 1.2× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-ABL1203 |
