Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1203A
AirTAC X-ABL1203A Locknut Right-Angle Terminal Specifications
- Model: X-ABL1203A
- Series: X-ABL Compact Pneumatic Terminal Series
- Material: SUS304 Stainless Steel (Anti-corrosion treatment)
- Thread Specification: PT1/8 (BSPP) Female Thread
- Locknut Type: Integrated Hexagon Locking Collar
- Max. Working Pressure: 1.0 MPa
- Temperature Range: -20℃ to 80℃
- Seal Material: NBR (Nitrile Rubber)
- Surface Finish: Electropolished
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 18mm(W) × 25mm(H)
- Torque Specification: 1.2~1.5 N·m (Installation)
- Flow Coefficient (Cv): 0.08
- Vibration Resistance: ≤50 m/s² (IEC 60068-2-6)
High-density forged terminal with precision-machined right-angle flow path, featuring zero-clearance locknut mechanism for vibration-proof tubing connections. The electropolished inner bore minimizes air turbulence and particle retention. Compatible with Φ4/6/8mm polyurethane/nylon tubing via push-to-connect installation.
- Compact pneumatic manifolds in robotic arms
- Tool-changing interfaces for CNC machines
- Modular assembly stations with space constraints
- Medical gas distribution panels
- Semiconductor handling equipment
Installation protocol:
Apply 2.5±0.5 wraps of PTFE tape on male threads. Tighten locknut
until 1.5mm gap remains between collar and base, then perform final
90° torque rotation. Requires 200-hour leak retest in high-cycle systems.
| Property | Property Value |
|---|---|
| sku | X-ABL1203A |
