Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1204
AirTAC X-ABL1204 Locknut Right Angle Terminal Specifications
- Model: X-ABL1204
- Type: Locknut style right-angle terminal
- Thread standard: PT1/4 (BSPP) / NPT1/4 optional
- Material: Brass (surface nickel-plated)
- Seal material: NBR rubber (FKM available for special orders)
- Operating pressure: 0.1-1.0 MPa (14.5-145 PSI)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Weight: 32g ±1g
- Dimensions: 28mm(L) × 24mm(W) × 22mm(H)
- Torque specification: 1.5-2.0 N·m during installation
- Flow coefficient (Cv): 0.15
- Compatibility: Works with Φ4/Φ6/Φ8mm PU/Nylon tubing
- Certification: RoHS compliant, ISO 9001:2015
Precision-engineered right-angle terminal with integrated locknut for secure pneumatic connections in confined spaces. Features triple-sealing structure (thread seal, tube grip seal, and O-ring) for leak-free performance. Nickel plating provides corrosion resistance in humid environments.
- Compact pneumatic manifolds in robotics
- Medical equipment air circuit junctions
- CNC machine tool pneumatic subsystems
- Packaging machine actuator connections
- Semiconductor manufacturing gas lines
Installation protocol:
Hand-tighten until snug, then apply 1/4 turn with wrench.
Always use two wrenches - one to hold base fitting and another
to tighten locknut. Avoid thread sealant; relies on metal-to-metal sealing.
| Property | Property Value |
|---|---|
| sku | X-ABL1204 |
