Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL1204A
AirTAC X-ABL1204A Locknut Right Angle Terminal Specifications
- Model: X-ABL1204A
- Type: Locknut-style right angle terminal (male thread)
- Thread specification: PT1/4 (BSPP 1/4")
- Material: Brass with nickel-plated finish
- Temperature range: -20℃ to 80℃
- Max working pressure: 1.5 MPa (217 psi)
- Seal material: NBR (Nitrile rubber)
- Torque specification: 1.5-2.0 Nm (13.3-17.7 lb-in)
- Weight: ~50g (1.76 oz)
- Dimensions: 25mm(L) × 18mm(W) × 25mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10-2000Hz, 5G max
Precision-engineered right-angle pneumatic connector featuring a 90° flow path optimization for space-constrained installations. The hexagonal locknut design ensures secure sealing against vibration loosening, with anodized markings for torque verification. Includes integrated O-ring groove for positive seal retention.
- Pneumatic valve manifold block connections
- Robotic arm tooling air supply interfaces
- CNC machine coolant line junctions
- Packaging equipment sensor air lines
- Semiconductor fab tool pneumatic networks
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads, hand-tighten
until seated then torque to 1.8Nm (±10%). Avoid cross-threading
by aligning axis perpendicular to mating surface. Pressure test
at 1.1x system pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-ABL1204A |
