Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL401
AirTAC X-ABL401 Elbow Terminal with Locknut Specifications
- Model: X-ABL401
- Type: Elbow terminal with swivel locknut (male thread to female thread)
- Material: Brass with nickel-plated finish
- Thread specification: PT1/8 (BSPT) male × PT1/8 (BSPT) female
- Operating pressure range: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Torque resistance: ≤2.5 N·m (installation torque)
- Leakage rate: ≤3 bubbles/min under 0.5 MPa
- Weight: 15.2±0.5g
- Dimensions: 30mm(L) × 20mm(W) × 20mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10–55Hz, 1.5mm amplitude
- Protection rating: IP54 (assembled state)
Precision-engineered 90° pneumatic connector featuring a dual-sealing structure (metal-to-metal + elastic seal) for leak-free transitions between components. The rotating locknut enables tool-free installation with 210° adjustment range, ideal for tight spaces requiring angular alignment. Compatible with air, inert gases, and vacuum systems.
- Pneumatic valve manifold block connections
- Robotic arm end-effector air supply lines
- Medical device gas circuit interfaces
- Packaging machine sensor air purge systems
- Semiconductor equipment vacuum line transitions
Installation protocol:
Apply 1.5–2 wraps of PTFE tape on male threads (clockwise winding). Hand-tighten locknut first,
then perform final tightening with 17mm open-end wrench while holding body stationary.
Pressure-test at 0.8MPa for 2 minutes post-installation.
