Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL801
AirTAC X-ABL801 Right Angle Terminal with Locknut Specifications
- Model: X-ABL801
- Thread standard: BSPP (G-thread)
- Port size: PT1/8 (G1/8)
- Material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber)
- Max working pressure: 1.5 MPa (217 psi)
- Min burst pressure: 4.5 MPa (653 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Tube compatibility: Φ6mm (1/4") OD pneumatic tubing
- Thread engagement length: 7.5mm
- Weight: 18g ±0.5g
- Dimensions: 15mm(W) × 25mm(L) × 15mm(H)
- Certification: RoHS compliant
- Torque specification: 1.2-1.5 N·m during installation
Precision-machined right-angle terminal featuring a swivel locknut design for secure 90° tubing connections in confined spaces. The chrome-plated brass body provides corrosion resistance, while the dual-seal structure (metal-to-metal + elastic seal) ensures leak-free performance under vibration. Compatible with air, vacuum, and inert gas systems.
- Compact pneumatic manifolds in robotic arms
- Vacuum pick-and-place systems
- Medical equipment gas line routing
- CNC machine tool coolant control
- Semiconductor manufacturing air circuits
- Packaging machine actuator connections
Installation guide:
Hand-tighten locknut before final torque application. Use two wrenches -
one to hold body hex (8mm) and another to tighten locknut (12mm).
Apply pipe sealant only on male threads, avoiding contact with NBR seals.
| Property | Property Value |
|---|---|
| sku | X-ABL801 |
