Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL801A
AirTAC X-ABL801A Locknut Right Angle Terminal Specifications
- Model: X-ABL801A
- Type: Reusable locknut-style right-angle terminal
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile) rubber
- Thread specification: M5×0.8 (ISO 228-1 standard)
- Operating pressure range: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃ (with silicone grease lubrication above 60℃)
- Installation torque: 0.8–1.2 N·m (recommended with torque wrench)
- Weight: 18.5±0.3g
- Dimensions: 21mm(L) × 16mm(W) × 14mm(H)
- Surface roughness: Ra ≤3.2μm (sealing surfaces)
- Leakage rate: ≤3 bubbles/min (ISO 6952 test standard)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
Precision-engineered right-angle pneumatic connector featuring dual-stage sealing (radial + axial) for leak-free transitions in compact spaces. The knurled locknut design enables tool-free maintenance while maintaining IP54 environmental protection. Compatible with PU/Nylon tubing (OD 4–6mm).
- Pneumatic valve manifold block interconnections
- Robotic end-effector air supply routing
- Medical device pneumatic circuit junctions
- Packaging machine sensor air line terminations
- Semiconductor tool vacuum/pressure port conversions
Installation protocol:
Apply thread sealant (LOCTITE 5452 recommended) to male threads before assembly.
Perform 5 full engagement cycles for optimal seal formation. Maximum 3 reuses
per component. Inspect O-ring for compression set after 2,000 pressure cycles.
| Property | Property Value |
|---|---|
| sku | X-ABL801A |
