Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL802A
AirTAC X-ABL802A Locknut Right Angle Terminal Specifications
- Model: X-ABL802A
- Type: Reusable compression fitting with locknut
- Thread standard: PT1/8 (BSPP)
- Material: Brass (nickel-plated surface)
- Seal type: Metal-to-metal sealing with O-ring backup
- Pressure rating: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃
- Torque specification: 1.5-2 Nm (installation)
- Surface hardness: HV200±20
- Weight: 18.5g±0.5g
- Dimensions: 25mm(L) × 18mm(W) × 20mm(H)
- Tube compatibility: Ø4mm polyurethane/nylon tubing
- Vibration resistance: ≤20m/s²
- Certification: RoHS compliant
Precision-engineered right-angle terminal for high-density pneumatic systems, featuring dual sealing (metal contact + EPDM O-ring) for leak-free operation. The knurled locknut enables tool-free maintenance while preventing accidental disconnections. Anodized aluminum alloy construction resists galvanic corrosion in humid environments.
- Robotic end-effector pneumatic connections
- CNC machine tool coolant line junctions
- Semiconductor manufacturing equipment
- Medical device pneumatic manifolds
- Electric vehicle battery cooling systems
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (except sealing surface).
Hand-tighten plus 1/4 turn with wrench. Maximum re-use cycles: 5 times.
Perform pressure test at 1.25× operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-ABL802A |
