Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL803
AirTAC X-ABL803 Lock Nut Right-Angle Terminal Specifications
- Model: X-ABL803
- Type: Push-to-connect lock nut 90° terminal
- Thread standard: Metric (M5x0.8)
- Material: Stainless steel body + Brass lock nut
- Tube compatibility: Ø4mm (1/8") OD pneumatic tubing
- Operating pressure: 0.2-1.5 MPa
- Temperature range: -20℃ to 80℃
- Thread engagement depth: 6±0.5mm
- Seal type: Integrated NBR O-ring
- Torque specification: 0.8-1.2 N·m (lock nut tightening)
- Weight: 12.5g ±0.3g
- Dimensions: 22mm(L) × 16mm(W) × 18mm(H)
- Surface treatment: Electroless nickel plating
- Vibration resistance: ≤50m/s²
- IP rating: IP40 (dust protected)
High-density forged terminal featuring anti-vibration lock nut design with 360° rotatable orientation. Precision-machined flow path ensures minimal pressure drop (ΔP ≤0.02MPa @1.0MPa). Includes built-in tube retention clip for secure connection. Compatible with ISO 8434-1/DIN 2353 standards.
- Multi-axis robotic end effectors
- CNC machine tool pneumatic clusters
- Modular pneumatic distribution blocks
- High-cycle automation test equipment
- Mobile hydraulic/pneumatic hybrid systems
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten).
Insert tube until audible click confirmation. Perform 3mm pull test
post-installation. Maximum angular deflection: ±3°.
| Property | Property Value |
|---|---|
| sku | X-ABL803 |
