Airtac X-ABL Union - Lock Nut Elbow Terminal X-ABL803A
AirTAC X-ABL803A Locknut Right Angle Terminal Specifications
- Model: X-ABL803A
- Type: Reusable push-to-connect terminal with swivel locknut
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile) O-ring
- Thread specification: G1/8 (BSPP) female thread
- Tube compatibility: Ø8mm (5/16") OD pneumatic tubing
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (static) / 0-60℃ (dynamic)
- Installation torque: 12-15 N·m (thread connection)
- Pressure test: 1.5 MPa (217.5 psi) burst pressure
- Weight: 42g ±1g
- Dimensions: 32mm(L) × 28mm(W) × 22mm(H)
- IP rating: IP54 (assembled with tubing)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-engineered right-angle terminal featuring a 360° rotatable locknut for flexible orientation adjustment in confined spaces. The dual-seal design combines metal-to-metal sealing (ISO 8434-1) with elastic NBR sealing for leak-free performance. Includes integrated tube retention clip for positive locking.
- Compact pneumatic manifolds in robotics
- Tool changer interfaces on CNC machines
- Modular assembly station plumbing
- Medical equipment gas line connections
- Packaging machine actuator networks
- 1. Cut tube square using tube cutter (max 0.5° angular error)
- 2. Deburr inner/outer edges with R0.3 max radius
- 3. Insert tube until audible "click" (requires 50N insertion force)
- 4. Hand-tighten locknut before final torque application
- 5. Perform 25% over-pressure leak test after installation
Maintenance note:
Replace O-rings every 500,000 cycles or 2 years (whichever comes first).
Use only PTFE-based lubricants. Avoid silicone oils which degrade NBR.
| Property | Property Value |
|---|---|
| sku | X-ABL803A |
