Airtac 2V Fluid Control Valve 2V02508B
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V02508B Fluid Control Valve Specifications
- Model: 2V02508B
- Type: 3-position 5-way pilot-operated (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.68 kg ±3%
- Dimensions: 70mm(L) × 45mm(W) × 102mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with 1℃ tolerance)
- Flow capacity: 1200 NL/min (at 0.5 MPa)
- Response time: ≤30ms (exhaust to atmosphere)
- Protection rating: IP67 (dust-tight & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with dual coil redundancy, featuring brass main body with anodized aluminum solenoid housing. Designed for precision bi-directional cylinder control in high-cycle applications. Includes manual override and surge suppression circuitry. Requires ISO 8573-1:2010 Class 3 lubricated air (40μm filtration).
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with dual-acting cylinders
- Food processing pneumatic actuators (FDA-compliant variants available)
- Battery manufacturing vacuum/pressure switching
Installation protocol:
Mount on vibration-damped surfaces using M5 mounting screws (not included).
Maintain ≥15mm clearance from adjacent components for heat dissipation.
Perform quarterly lubrication checks in high-cycling (>500,000 cycles/month) applications.
Critical note:
Always install downstream moisture separator when ambient humidity exceeds 60% RH.
Avoid continuous energization beyond 120 minutes without duty cycling.
| Property | Property Value |
|---|---|
| sku | 2V02508B |
| Port Size | PT1/4 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | DC24V |
