This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X120S — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X120S in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X120S
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X120S is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 120mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X120S (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke120 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X120S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X120S
A double acting compact cylinder with a rod leaving both covers, the ACPD100X120S delivers 3681.6 N in each direction at 0.5 MPa because both strokes work on the rod-side area. The 100 mm bore drives a 25 mm hard-chrome S45C rod through a hard-anodized aluminium body, with a fixed TPU bumper at each end and a 1/4" PT port. The through-rod resists rotation and side load, gives a symmetric mount, and the rear rod can carry a sensor flag. This model carries the optional -S magnet, so CMSE / DMSE reed or solid-state switches mount directly on the body.
The short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which is why it suits tight gantries and heavy clamping fixtures. At 0.5 MPa the usable working force is roughly 2209 N after derating, which lifts about 187 kg vertically with a 2:1 margin - enough to raise a loaded pallet fixture or a steel die set. Note that this ACPD is discontinued: the current-production drop-in is the ACED100X120, and you should confirm the ISO 21287 mounting dimensions before swapping.
Airtac ACPD Double Rod Compact Cylinder ACPD100X120S Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X120S |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X120S |
| Bore size | Ø100 mm |
| Stroke | 120 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X120S (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X120S
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×120 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X120S Is Used
Pallet-lift fixture on a machining line
With about 187 kg of vertical lift capacity at a 2:1 margin, the 100 mm double rod raises and lowers a loaded pallet fixture between machining stations, the through-rod keeping the platform guided on both sides.
Symmetric press station for aluminum die casting
Equal 3681.6 N force in both directions lets one cylinder eject and re-clamp a casting tray, while the rear rod carries a CMSE switch flag for position confirmation.
Gantry Z-axis on an automotive assembly cell
The short body saves roughly 50% of the length of an ISO 15552 profile cylinder, fitting the 120 mm stroke into a low gantry head that lifts and seats door trim panels.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X120S with the ACED100X120S
For this 120 mm stroke the 100 mm bore gives 3681.6 N both ways at 0.5 MPa and 5154.2 N at 0.7 MPa, with a peak of 750.8 kgf at 1.0 MPa. If your load needs under 1458 N at 0.5 MPa, the 63 mm bore saves space; if you need over 3681 N, step up only via the ACED family since ACPD stops here. The piston does not hold position when air is lost - add a rod lock or pilot check for a held load. FA/FB flange and LB foot mounts bolt to the ISO 21287 face, and the fitted -S magnet accepts CMSE / DMSE switches. Order the ACED100X120 as the current replacement and verify mounting dimensions first.
Replacement checklist
- ✓ Current-production ACE → ACED100X120S
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X120S FAQ
Yes - as a double-rod cylinder both strokes use the rod-side area, so force is equal both ways: 3681.6 N at 0.5 MPa, 5154.2 N at 0.7 MPa, and a maximum of 750.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), speed 30-500 mm/s, port 1/4" PT, rod thread M16x1.5 female.
The ACPD family is no longer in production. The current drop-in is the ACED100X120 (swap the P for an E), which matches the same bore, stroke and force class in the ISO 21287 short-body format - confirm the mounting dimensions before swapping. On this S-coded model the optional -S magnet is fitted, so CMSE / DMSE reed or solid-state switches can be mounted; without the -S code there is no magnet.
