This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X15B — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X15B in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X15B
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X15B is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 15mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X15B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke15 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X15B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X15B
A double acting compact cylinder with a rod leaving both covers, the ACPD100X15B pushes and pulls with identical output: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa in each direction, since both strokes work on the rod-side area. The 100 mm bore drives a 25 mm hard-chrome S45C rod through a hard-anodized aluminium body, with a fixed TPU bumper at each end and speeds of 30-500 mm/s. This model is discontinued; the current-production successor is the ACED100X15.
The through-rod resists rotation and side load and gives a symmetric mount, so the rear rod can carry a sensor flag or a second tooling plate. The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which suits tight presses and clamping fixtures. In practice, plan on roughly 2209 N (about 225 kg of push) at 0.5 MPa rather than the full rating, and the same force is available on the return stroke. Note that no magnet is fitted on this version; the optional -S code adds one for CMSE / DMSE switches.
Airtac ACPD Double Rod Compact Cylinder ACPD100X15B Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X15B |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X15B |
| Bore size | Ø100 mm |
| Stroke | 15 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X15B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X15B
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X15B Is Used
Baler ram return
Equal 3681.6 N force on both strokes lets the same 100 mm cylinder compact and retract a small baler platen without a larger return bore.
Press stamp transfer
The rear 25 mm rod carries a workpiece flag on a stamping press, so the PLC tracks position without extra tooling on the front rod.
Pallet pusher gate
A 15 mm stroke nudges pallets onto a conveyor gate in a warehouse, with the through-rod taking the side load of off-center loads.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X15B with the ACED100X15B
At 3681.6 N per direction this is the top of the ACPD range; if your load needs less than 2356.2 N at 0.5 MPa, the 80 mm bore saves air and cost, while there is no larger bore in the family. The 15 mm stroke suits short clamp-and-release moves, and 300 mm is the maximum standard stroke for this bore. The male rod thread (B code) takes I/Y knuckles directly, and FA/FB flange or LB foot mounts bolt to the ISO 21287 face. A plain double-rod cylinder drifts when air is lost, so add a rod lock or pilot check for a held load. Order the ACED100X15 as the drop-in replacement and confirm the ISO 21287 mounting dimensions before swapping.
Replacement checklist
- ✓ Current-production ACE → ACED100X15B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X15B FAQ
Because a rod exits both covers, force is equal in both directions: 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa, on the rod-side area. Peak output at 1.0 MPa is 750.8 kgf. Operating range is 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, and speed runs 30-500 mm/s.
The ACPD family is no longer produced. Order the ACED100X15, the ISO 21287 successor with the same 100 mm bore, 15 mm stroke and force class. Confirm the ISO 21287 mounting dimensions before swapping, since the ACP was built to the DIN standard, and check FA/FB flange or LB foot hole patterns against your fixture.
