This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ACED100X15SB — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ACED100X15SB in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB
The AirTAC Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB is a double acting, double rod DIN-standard tight/compact air cylinder with a Ø100mm bore and 15mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACED100X15SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke15 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM16×1.5
- StatusDiscontinued → ACED100X15SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB
This is a double acting compact cylinder with a rod exiting BOTH covers, so the 100 mm bore delivers the same 3681.6 N at 0.5 MPa (5154.2 N at 0.7 MPa) whether it pushes or pulls - both strokes work on the rod-side area. The 25 mm through-rod resists rotation and side load, gives a symmetric mount, and the rear rod can carry a sensor flag. The 15 mm stroke suits short clamp-and-return moves at 30-500 mm/s. Note: the ACPD family is discontinued; the current-production drop-in is the ACED100X15, so confirm ISO 21287 mounting dimensions before swapping.
The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it fits tight presses, guarding and gantry fixtures. The hard-anodized aluminium body carries a fixed TPU bumper at each end, and the male rod thread (B code) plus the fitted -S magnet lets you attach rod knuckles and CMSE / DMSE switches directly. In practice, plan on about 2209 N of real work at 0.5 MPa (roughly 60% of rating), which lifts about 187 kg vertically with a 2:1 margin.
Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB Technical Specifications
| Model | Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB |
|---|---|
| Series | ACPD DIN compact cylinder (discontinued) |
| Replacement | ACED100X15SB |
| Bore size | Ø100 mm |
| Stroke | 15 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACED100X15SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3682 N |
| 0.7 MPa | 5154 N |
| Max (@1.0 MPa) | 751 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB
| ACPD | DIN compact cylinder (double-rod, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB Is Used
Short-stroke press fixture
The 15 mm stroke and 3681.6 N per side at 0.5 MPa suit a stamping or marking head on an aluminium extrusion line where full travel is never needed.
Symmetric clamp on a machining jig
With a rod on both covers, a CNC fixture can clamp from either end with identical 5154.2 N force at 0.7 MPa - no re-plumbing for pull side.
Packaging line reject pusher
The through-rod resists side load from cartons on a bottling conveyor, and the fitted magnet with a DMSE switch confirms the push position each cycle.
Replacing the Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB with the ACED100X15SB
At 3681.6 N per side at 0.5 MPa, the 100 mm bore covers heavy clamping and pressing; step down to the 80 mm bore (2356.2 N) if the load is lighter, or up to nothing larger in this range - 100 mm is the biggest bore offered. Remember the piston drifts if air is lost, so add a rod lock or pilot check where a load must stay put. FA/FB flange and LB foot mountings bolt to the standard face, and this unit already carries the optional -S magnet for CMSE / DMSE switches. Order the ACED100X15 as the current replacement and verify the ISO 21287 footprint first.
Replacement checklist
- ✓ Current-production ACE → ACED100X15SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPD Double Rod Compact Cylinder ACPD100X15SB FAQ
Yes - because a rod exits both covers, both strokes use the rod-side area. Output is 3681.6 N at 0.5 MPa and 5154.2 N at 0.7 MPa, equal push and pull, with a maximum of 750.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, air filtered to 40 um, temperature -20 to +70 C. This model is discontinued; the ACED100X15 is the current replacement in the same force class.
Order the ACED100X15 (same P-to-E swap, same 100 mm bore and 15 mm stroke) and confirm the ISO 21287 mounting dimensions against your fixture, since the ACP was built to a DIN-standard footprint. This unit carries the optional -S magnet, so CMSE reed or DMSE solid-state switches mount directly on the 25 mm through-rod. The fixed TPU bumpers at both ends only soften end-of-travel - they do not hold a load if air is lost, so use a rod lock or pilot check for that.
