Airtac ACQ Ultra Thin Air Cylinder ACQ12X10B
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X10B Ultra-Thin Cylinder Specifications
- Model: ACQ12X10B
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Elastic buffer
- Mounting options: Foot/Flange (MF1/MF3 optional)
- Port size: M5x0.8
- Piston rod thread: M6x1
- Body material: Aluminum alloy (anodized)
- Seal material: NBR
- Weight: 0.25kg ±5%
- Dimensions: 45mm(L) × 32mm(W) × 12mm(H)
Ultra-compact cylinder with 12mm profile height optimized for confined spaces. Features integrated air ports and precision honed tube for smooth operation. Requires 1-3μm filtered air with ISO VG32 lubricant (optional oil-free operation). Compatible with vacuum applications when paired with magnetic switches.
- Semiconductor wafer handling robots
- Optical lens positioning mechanisms
- PCB depaneling machine actuators
- Automated test equipment (ATE) fixtures
- Medical device pneumatic clamps
Installation note:
Maintain parallel alignment during mounting. Maximum side load capacity 3N·m.
For vertical installations exceeding 45° angle, use guide mechanisms. Lubricate every 500km stroke
under normal conditions (extend interval with AirTAC Super Lube Kit).
| Property | Property Value |
|---|---|
| sku | ACQ12X10B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
