Airtac ACQ Ultra Thin Air Cylinder ACQ12X15B
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X15B Ultra-Slim Cylinder Specifications
- Model: ACQ12X15B
- Type: Single-acting spring return cylinder
- Bore size: 12mm
- Stroke: 15mm
- Operating pressure: 0.05–0.9 MPa
- Port thread: M5×0.8
- Operating medium: Clean air (Lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Fixed cushion (Rubber buffer)
- Seal material: NBR/PU
- Piston material: Aluminum alloy with hard anodization
- Rod material: Stainless steel SUS304
- Weight: 0.35kg
- Dimensions:
- Body length: 55mm
- Width (Mounting face): 20mm
- Height (Including rod): 68mm
- Stroke tolerance: ±1mm
- ISO standard: 6432 compliant
- Protection rating: IP54
This ultra-compact cylinder features a space-saving design with 55% reduced installation height compared to standard models. The anodized aluminum construction ensures corrosion resistance while maintaining precise linear motion. The built-in rubber cushion minimizes end-impact noise (<65dB) and extends service life to over 3,000km travel distance. Compatible with vacuum applications when paired with special seals.
- PCB handling robots in electronics assembly
- Precision clamping in medical device manufacturing
- Miniature sorting mechanisms in packaging lines
- Automated test equipment positioning stages
- Semiconductor wafer processing systems
Installation guidelines:
For optimal performance, maintain alignment within ±0.5° angular misalignment.
Use C-shaped clevis mounting (AMQ series recommended) to prevent side load.
Lubricate every 3 months with ISO VG32 turbine oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | ACQ12X15B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
