Airtac ACQ Ultra Thin Air Cylinder ACQ12X15SLB
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X15SLB Ultra-Slim Cylinder Specifications
- Model: ACQ12X15SLB
- Type: Single-acting spring return (push type)
- Bore size: Φ12mm
- Stroke: 15mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable buffer
- Mounting style: Foot mounting (optional flange/axial mount)
- Material: Aluminum alloy body, stainless steel piston rod
- Seal material: NBR rubber
- Weight: 0.18kg ±5%
- Dimensions:
- Total length (retracted): 59mm
- Body width: 24mm
- Height (with mounting foot): 34mm
- Piston rod thread: M4x0.7
- Protection rating: IP40 (IP67 with optional rod cover)
- Lubrication: Pre-lubricated (Do not mix with petroleum-based oils)
Industry's thinnest 12mm bore cylinder featuring 34% slimmer profile than standard models. Precision-ground rod with hard chrome plating ensures ≤0.5mm repeat positioning accuracy. The anodized body resists chemical corrosion in harsh environments. Special low-friction seals enable smooth operation at 50-800mm/s speeds.
- PCB board clamping in electronics assembly
- Micro-parts positioning in semiconductor handlers
- Medical device actuation (IV pump mechanisms)
- Light-duty grippers in collaborative robots
- Paper feed mechanisms in office automation
Installation note:
Maintain ≤0.5mm alignment tolerance during mounting. Use flexible couplings when connecting to guided mechanisms. For vertical mounting, position piston rod downward to prevent debris accumulation. Requires 5μm filtered dry air with 1-10mg/m³ oil mist.
| Property | Property Value |
|---|---|
| sku | ACQ12X15SLB |
| Mounting Type | Axial Mounting Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
