Airtac ACQ Ultra Thin Air Cylinder ACQ12X20B
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X20B Ultra-Thin Cylinder Specifications
- Model: ACQ12X20B
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Elastic buffer
- Port size: M5x0.8 (dual ports)
- Mounting type: Basic side mounting holes
- Seal material: NBR (nitrile rubber)
- Piston rod material: Stainless steel (SUS304)
- Protection rating: IP40
- Max speed: 500 mm/s
- Lubrication: Non-lube operation (oil-free)
- Durability: 2,000km (ISO 15552 standard)
- Weight: 0.25kg ±3%
- Dimensions: 54mm(L) × 40mm(W) × 40mm(H)
The ACQ12X20B represents AirTAC's ultra-compact cylinder series featuring a 30% slimmer profile than standard models. Precision-machined guide grooves ensure smooth linear motion, while the anti-rotation design maintains positional accuracy. Requires 5μm filtered air with dew point -25℃ below ambient.
- PCB handling robots in electronics manufacturing
- Medical device actuation mechanisms
- Compact pick-and-place units with limited Z-axis space
- Automated door locking systems
- Precision optical equipment positioning
Installation note:
Optimal performance achieved when mounted horizontally. Use shim washers for angular alignment compensation.
Avoid side load exceeding 2N. Lubricate rod end weekly in high-cycle applications (>5Hz).
| Property | Property Value |
|---|---|
| sku | ACQ12X20B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
