Airtac ACQ Ultra Thin Air Cylinder ACQ12X25B
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X25B Ultra-Thin Cylinder Specifications
- Model: ACQ12X25B
- Bore size: 12mm
- Stroke: 25mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Fixed rubber buffer (both ends)
- Mounting style: Basic type (no built-in mounting features)
- Port size: M5x0.8 (standard) with optional NPT1/8 adapter
- Piston rod thread: M6x1 (external)
- Seal material: NBR + PU combination
- Protection rating: IP40 (dust protected)
- Weight: 0.24kg ±5%
- Dimensions: 90mm(L) × 24mm(W) × 24mm(H)
- Piston speed: 50–800 mm/s (optimal performance at 300–500 mm/s)
- Lubrication requirement: Pre-lubed (requires ISO VG32 oil mist lubrication for maintenance)
Ultra-compact cylinder featuring a 7mm profile height reduction compared to standard models, achieving 45% space savings. Precision-machined aluminum body with hard anodized finish ensures corrosion resistance. Integrated guide rod design minimizes lateral deflection (max 0.3mm at full extension). Includes adjustable magnetic sensor slots compatible with D-A93 series sensors.
- High-density robotic end effectors in electronics assembly
- Semiconductor wafer handling systems
- Medical device positioning mechanisms
- Packaging machine clamp actuators
- Automated optical inspection equipment
- Cleanroom-compatible automation (low particle generation)
Installation guidelines:
Requires minimum 0.3Nm tightening torque for mounting brackets.
For horizontal mounting, use dual rod support brackets when stroke exceeds 50mm.
Maintain 40μm filtered air supply with dew point -20℃ below ambient temperature.
| Property | Property Value |
|---|---|
| sku | ACQ12X25B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
