Airtac ACQ Ultra Thin Air Cylinder ACQ12X25S
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X25S Ultra-Thin Cylinder Specifications
- Model: ACQ12X25S
- Bore size: 12mm
- Stroke: 25mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) with optional NPT1/8 adapter
- Cushioning type: Fixed rubber buffer + adjustable cushion
- Material: Aluminum alloy body (anodized), chromium-plated piston rod
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Piston speed: 50–800 mm/s (optimal range)
- Weight: 0.15 kg (without accessories)
- Dimensions: 55mm(L) × 32mm(W) × 12.5mm(H) (compact section height)
- Mounting types: Standard (no base) with optional foot/mid-flange
- ISO standard: 6432 compliant
- Lubrication: Pre-lubricated (maintenance-free for 500km stroke)
Ultra-slim profile cylinder optimized for space-constrained automation applications. Features double-acting operation with corrosion-resistant construction and precision honed tube. The 0.1mm dynamic seal clearance design minimizes air consumption while maintaining ≤0.5mm lateral play. Includes magnetic piston for position sensing compatibility.
- PCB handling robots in electronics manufacturing
- Medical device positioning mechanisms
- Compact packaging machine grippers
- Semiconductor wafer processing equipment
- Automated microscope stage movement
- Precision dosing valve actuators
Installation notes:
- Max lateral load: ≤5N at full extension
- Use SMC type magnetic switches (compatible with AISI 430F piston rod)
- Recommended air dryness: Pressure dew point ≤3℃ below ambient
- Break-in period: Operate at 50% rated speed for first 500 cycles
| Property | Property Value |
|---|---|
| sku | ACQ12X25S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
