Airtac ACQ Ultra Thin Air Cylinder ACQ12X25SBH
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X25SBH Ultra-Slim Cylinder Specifications
- Model: ACQ12X25SBH
- Series: ACQ Compact Cylinder
- Bore size: 12mm
- Stroke: 25mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Rubber buffer (both ends)
- Mounting style: Basic foot mounting (ISO 15552 compatible)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston speed: 50–800 mm/s
- Seal material: NBR + Special polyurethane alloy
- Rod material: Stainless steel SUS304
- Body material: Anodized aluminum alloy
- Weight: 0.23 kg (excluding accessories)
- Dimensions:
- Length: 112mm (full retracted)
- Width: 24mm (body diameter)
- Height: 32mm (mounting base to rod center)
ACQ series ultra-compact cylinder featuring 35% reduced installation space compared to standard models. Precision-ground rod with multi-layered sealing system ensures ≤0.5mm/s creep speed under load. Optional magnetic piston version (add "-M" suffix) for position sensing. Designed for ISO 8573-1:2010 air quality standards.
- High-density PCB board handling robots
- Medical device actuation systems
- Semiconductor wafer transfer mechanisms
- Packaging machine clamp positioning
- Automated optical inspection (AOI) equipment
Installation guidelines:
Use Cushion Needle Valve (ASN series) for speed adjustment.
Maintain ≤0.3mm alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | ACQ12X25SBH |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
