Airtac ACQ Ultra Thin Air Cylinder ACQ12X30
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X30 Ultra-Thin Cylinder Specifications
- Model: ACQ12X30
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 30mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Weight: 0.15kg (excluding accessories)
- Dimensions: 68mm(L) × 24mm(W) × 25mm(H)
Ultra-compact cylinder with 25mm height profile optimized for space-constrained automation systems. Features dual anti-rotation guide rods for enhanced lateral load capacity (max 3N·m). Maintenance-free design with self-lubricating bushings and IP54 protection against particulate ingress.
- PCB handling robots in electronics manufacturing
- Medical analyzer sample tray positioning
- Semiconductor wafer clamping mechanisms
- Packaging machine flap sealing actuators
- 3D printer Z-axis auto-bed leveling systems
Installation note:
Maximum allowable misalignment angle: ±2°. For vertical mounting,
use auxiliary guide mechanisms when handling payloads >0.5kg.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃.
- MFH-4-12: Compact magnetic sensor (2-wire NPN)
- ACQ-BF12: Side flange mounting bracket
- ACQ-FS12: Front pivot mounting clevis
| Property | Property Value |
|---|---|
| sku | ACQ12X30 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
