Airtac ACQ Ultra Thin Air Cylinder ACQ12X30B
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X30B Ultra-Thin Cylinder Specifications
- Model: ACQ12X30B
- Type: Double-acting ultra-slim cylinder
- Bore size: 12mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Max theoretical thrust: 8.1kgf (at 0.6MPa)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Cushioning: Adjustable rubber buffer
- Piston rod material: SUS304 stainless steel
- Barrel material: Aluminum alloy with hard anodizing
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 185g ±5g
- Dimensions:
- Body length: 66mm (excluding rod)
- Total length at full extension: 96mm
- Width: 32mm (including mounting tabs)
- Height: 32mm (square profile)
- Mounting style: Basic type with foot mounting holes
- Lubrication: Pre-lubricated (Grease-free operation)
- ISO standard: Compliant with ISO 6432
The ACQ12X30B represents AirTAC's space-optimized pneumatic solution, featuring a 4mm wall thickness barrel for maximum strength in minimal space. Its square cross-section prevents rotation during operation, while the chrome-plated piston rod resists corrosion in humid environments. The cylinder achieves 50% weight reduction compared to standard models through precision aluminum extrusion.
- PCB handling robots in electronics assembly
- Medical device actuation (e.g., analyzer arms)
- Compact packaging machine ejectors
- Semiconductor wafer transfer systems
- Automated optical inspection (AOI) equipment
- Cleanroom-compatible machinery
Installation guidelines:
Maintain ≤0.3mm parallelism between rod and guide structures.
Use flexible couplings to compensate for misalignment.
For vertical mounting, add 10-15% extra thrust capacity margin.
| Property | Property Value |
|---|---|
| sku | ACQ12X30B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
