Airtac ACQ Ultra Thin Air Cylinder ACQ12X60S
$28.60
Regular price
$36.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQ12X60S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
Installation note:
Maximum side load 3N. For vertical mounting, use ≥0.3 MPa pressure to prevent seal sticktion.
Lubricate with ISO VG32 pneumatic oil if operated below -5℃.
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ12X60S Ultra-Thin Cylinder Specifications
- Model: ACQ12X60S (Magnetic switch ready)
- Bore size: 12mm
- Stroke: 60mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable rubber bumper
- Port size: M5x0.8 (G1/8 adapter optional)
- Piston speed: 50–800 mm/s
- Mounting style: Basic type (no pre-fixed mounts)
- Rod material: Stainless steel SUS304
- Body material: Anodized aluminum alloy
- Seal type: NBR seals (FDA compliant option available)
- Weight: 0.32 kg ±5%
- Dimensions: 78mm(L) × 50mm(W) × 50mm(H)
Industry's thinnest 12mm bore cylinder (only 50mm width profile) with precision ground rod and dual anti-rotation guides. Features wear-resistant rod bushing and multi-lip seals for ≤0.05mm internal leakage. Includes auto-switch slots for S-08 series sensors.
Ideal for:
- PCB handling robots in electronics assembly
- Micro-pneumatic grippers in pick-and-place systems
- Medical device actuation requiring low inertia
- Space-constrained packaging machinery doors
- Cleanroom applications (optional low-particle version)
Installation note:
Maximum side load 3N. For vertical mounting, use ≥0.3 MPa pressure to prevent seal sticktion.
Lubricate with ISO VG32 pneumatic oil if operated below -5℃.
| Property | Property Value |
|---|---|
| sku | ACQ12X60S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 60mm |
