Airtac SC125-160 Standard Cylinder SC160X50
The AirTAC Airtac SC125-160 Standard Cylinder SC160X50 is a genuine double-acting standard air cylinder with a Ø160mm bore and 50mm stroke, PT3/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ160 mm
- Stroke50 mm
- Port sizePT3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 29 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SC125-160 Standard Cylinder SC160X50
The AirTAC SC160X50 is a double-acting pneumatic cylinder delivering substantial force in a compact 50 mm stroke. At 0.5 MPa it provides 10053 N push and 9425 N pull, scaling to 18095 N at the 0.9 MPa maximum operating pressure.
This model features a 40 mm diameter piston rod with M36x2 threads and PT3/4 ports. The tie-rod construction includes an adjustable air cushion (29 mm length) to decelerate the 160 mm bore piston smoothly, and the standard TPU seals suit operating temperatures from -20 to +70 °C.
Airtac SC125-160 Standard Cylinder SC160X50 Technical Specifications
| Model | Airtac SC125-160 Standard Cylinder SC160X50 |
|---|---|
| Series | SC big-bore tie-rod cylinder (ISO 6430 class) |
| Bore size | Ø160 mm |
| Stroke | 50 mm |
| Acting type | Double acting |
| Port size | PT3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 29 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10053 N | 9425 N |
| 0.7 MPa | 14074 N | — |
| Max (approx.) | 2050 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC125-160 Standard Cylinder SC160X50
| SC | Standard tie-rod cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC125-160 Standard Cylinder SC160X50 Is Used
Heavy Press Tool Actuation
Powers short-stroke clamping and pressing fixtures with 10 kN force at 0.5 MPa, ideal for holding workpieces during welding or assembly.
Material Stops and Gates
Deploys a robust stop pin or diverter gate on heavy-duty conveyor lines, using the 50 mm stroke for quick, repeatable positioning of pallets.
Die Cushion Ejection
Provides a powerful, controlled ejection stroke in metal stamping dies, leveraging the adjustable cushion to manage impact at the end of the 50 mm travel.
Is the Airtac SC125-160 Standard Cylinder SC160X50 the Right Cylinder?
For applications needing slightly less force in a similar footprint, the 125 mm bore SC125 series offers 6136 N push at 0.5 MPa. If 50 mm stroke is insufficient, the SC160 supports standard strokes up to 1500 mm. When replacing an existing cylinder, match five points: 160 mm bore, 50 mm stroke, PT3/4 port thread, basic (no bracket) mounting, and confirm whether a magnet (-S) is required for sensors.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC125-160 Standard Cylinder SC160X50 FAQ
At 0.7 MPa operating pressure, the SC160X50 produces a theoretical push force of 14074 N. The maximum force at 0.9 MPa is 18095 N. Always apply a safety factor for dynamic loads.
Yes, you would order model SC160X50TC, which includes the centre trunnion and TCM1 bracket. The basic SC160X50 model has no mounting accessories; you can add the TC mount or foot (LB), flange (FA/FB), or clevis (CA/CB) brackets separately using the F-SC160 accessory series.
