This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ATE100X15SB — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ATE100X15SB in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB
The AirTAC Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB is a single acting, pull (spring return) DIN-standard tight/compact air cylinder with a Ø100mm bore and 15mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ATE100X15SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke15 mm
- Port size1/4"
- Acting typeSingle acting, pull (spring return)
- Rod threadM16×1.5
- StatusDiscontinued → ATE100X15SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB
A single acting pull cylinder with spring return, the ATP100X15SB keeps its 25 mm rod extended by a spring and retracts it with air, delivering 3395.3 N at 0.5 MPa (4867.9 N at 0.7 MPa) net of the spring. The 100 mm bore feeds through a 1/4" port and needs at least 0.2 MPa to overcome the spring. This unit carries the optional -S magnet, so CMSE / DMSE switches can be fitted for end-of-stroke signals. Note that the ATP family is discontinued; the current-production drop-in is the ATE100X15.
The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it suits tight clamping stations and guarded assemblies. For sizing, treat about 2037 N (roughly 173 kg lifted vertically with a 2:1 margin) as the realistic working pull at 0.5 MPa rather than the full rating. A fixed TPU bumper at each end decelerates the rod, and the male rod thread (B code) on the S45C hard-chrome rod bolts to standard knuckles. Confirm the ATE100X15 ISO 21287 mounting dimensions before swapping, since this model follows the DIN-standard footprint.
Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB Technical Specifications
| Model | Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB |
|---|---|
| Series | ATP DIN compact cylinder (discontinued) |
| Replacement | ATE100X15SB |
| Bore size | Ø100 mm |
| Stroke | 15 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 25 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ATE100X15SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 3395.3 N |
| 0.7 MPa | 4867.9 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB
| ATP | DIN compact cylinder (single-acting pull, spring-return, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB Is Used
Press unloading clamp
Spring holds the 25 mm rod retracted-free above a stamped bracket; air pulls it 15 mm clear at 3395.3 N so the part drops off the die on a 400 mm/s return.
Fixture retraction gate
On a CNC pallet changer the spring keeps the locking pin extended home; 0.5 MPa air retracts it in 15 mm before the pallet rotates, and a DMSE switch confirms the pulled position.
Battery latch release
In an AGV battery bay the spring-extended hook secures the pack; the cylinder pulls it back with 3395.3 N net force, releasing on air loss to the extended fail-safe state.
Replacing the Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB with the ATE100X15SB
At 100 mm bore this is the largest pull in the range: 3395.3 N at 0.5 MPa versus 2159.1 N for the 80 mm bore, so step down only if your load is under about 1300 N of real work. If 3395.3 N is marginal, no larger bore exists in ATP - move to the ATE100X15 or a double-acting ACE for more force. Strokes stay short on spring-return pull cylinders; 15 mm sits well inside the standard range for this bore. The male rod thread suits directly threaded tooling, and the -S magnet this model carries pairs with CMSE / DMSE switches. Order the ATE100X15 as the current replacement and verify ISO 21287 mounting dimensions first.
Replacement checklist
- ✓ Current-production ACE → ATE100X15SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ATP Single Acting Port Compact Cylinder ATP100X15SB FAQ
It is a single acting pull cylinder: the spring extends the rod and air retracts it. Pull is 3395.3 N at 0.5 MPa and 4867.9 N at 0.7 MPa, both net of the return spring, with a minimum working pressure of 0.2 MPa. Plan on about 2037 N of usable pull at 0.5 MPa - roughly a 173 kg vertical lift with a 2:1 margin. Operating range is 0.2-1.0 MPa (28-145 psi), proof 1.5 MPa (215 psi), speed 50-500 mm/s, air filtered to 40 um.
Order the ATE100X15, the current-production ISO 21287 successor: swap the P for an E and you get the same 100 mm bore, 15 mm stroke and force class in a short compact body. Because the ATP follows the DIN-standard format, confirm the ISO 21287 mounting dimensions and the FA/FB flange, LB foot or CA/CB clevis interfaces before swapping. This unit's -S magnet carries over as an option on the ATE for CMSE / DMSE switch mounting.
