This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ATE100X20S — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ATE100X20S in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ATP Single Acting Port Compact Cylinder ATP100X20S
The AirTAC Airtac ATP Single Acting Port Compact Cylinder ATP100X20S is a single acting, pull (spring return) DIN-standard tight/compact air cylinder with a Ø100mm bore and 20mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ATE100X20S (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke20 mm
- Port size1/4"
- Acting typeSingle acting, pull (spring return)
- Rod threadM16×1.5
- StatusDiscontinued → ATE100X20S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATP Single Acting Port Compact Cylinder ATP100X20S
A single acting pull cylinder with spring return, the ATP100X20S uses a 100 mm bore to deliver 3395.3 N of pull at 0.5 MPa (4867.9 N at 0.7 MPa), both figures already net of the return spring. The spring holds the rod extended at rest, so the unit fails to the extended position on air loss, and at least 0.2 MPa is needed before air can beat the spring. This model carries the optional -S magnet, so CMSE or DMSE reed and solid-state switches can be mounted directly on the body. It is discontinued; the current-production replacement is the ATE100X20.
The hard-anodized aluminium body follows the ISO 21287 short format, saving roughly 50% of the mounting length of an ISO 15552 profile cylinder, which matters in tight press fixtures and gantry clamps. For sizing, plan on about 2037 N of real work at 0.5 MPa rather than the full rating, and expect roughly 173 kg of vertical lift capability with a 2:1 margin. A fixed TPU bumper sits at both ends, the S45C rod is hard-chrome plated with an M16x1.5 female thread, and the air port is 1/4" PT.
Airtac ATP Single Acting Port Compact Cylinder ATP100X20S Technical Specifications
| Model | Airtac ATP Single Acting Port Compact Cylinder ATP100X20S |
|---|---|
| Series | ATP DIN compact cylinder (discontinued) |
| Replacement | ATE100X20S |
| Bore size | Ø100 mm |
| Stroke | 20 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 25 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ATE100X20S (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 3395.3 N |
| 0.7 MPa | 4867.9 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ATP Single Acting Port Compact Cylinder ATP100X20S
| ATP | DIN compact cylinder (single-acting pull, spring-return, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×20 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ATP Single Acting Port Compact Cylinder ATP100X20S Is Used
Baling press retraction
Pulls a 20 mm stroke platen back against the spring in a small scrap or powder baling head, delivering 3395.3 N at 0.5 MPa where the spring-extended home position is the safe rest state.
Die cart latch release
Retracts a heavy latch pin on a stamping die cart; the spring keeps the latch engaged whenever air is lost, and the -S magnet feeds a DMSE switch to the PLC for pin-withdrawn confirmation.
Pallet stopper drop
Drops a roller-conveyor stop blade for pallets up to about 170 kg equivalent load, using the 2:1 margin on the 173 kg vertical-lift figure and the short ISO 21287 body under the frame rail.
Replacing the Airtac ATP Single Acting Port Compact Cylinder ATP100X20S with the ATE100X20S
At this bore size the step below is the 80 mm frame at 2159.1 N pull at 0.5 MPa, and there is no larger bore in the family, so 100 mm is the top of the range. If your clamp or press needs more than about 2037 N of usable force at 0.5 MPa, this is the right class; if less, the 80 mm saves space and air. Remember the spring returns the rod to extended on air loss and will not hold a mid-stroke position. FA/FB flange, LB foot and CA/CB clevis mounts bolt to the ISO 21287 face, and the -S magnet on this unit accepts CMSE / DMSE switches. Order the ATE100X20 as the drop-in successor and confirm the ISO 21287 mounting dimensions before swapping.
Replacement checklist
- ✓ Current-production ACE → ATE100X20S
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ATP Single Acting Port Compact Cylinder ATP100X20S FAQ
Pull is 3395.3 N at 0.5 MPa and 4867.9 N at 0.7 MPa, both net of the return spring. Air pressure range is 0.2-1.0 MPa (28-145 psi) with 1.5 MPa (215 psi) proof, speed 50-500 mm/s, and the 1/4" PT port serves the 100 mm bore. A practical plan is about 2037 N of real work at 0.5 MPa, or roughly 173 kg of vertical lift with a 2:1 margin. Minimum working pressure is 0.2 MPa.
Order the ATE100X20, the current ISO 21287 successor: swap the P for an E and you get the same 100 mm bore, 20 mm stroke and force class. Confirm the ISO 21287 mounting dimensions before the swap since the ATP follows the DIN-standard compact format. This ATP100X20S carries the optional -S magnet, so CMSE or DMSE reed and solid-state switches mount on the body; the successor keeps the same sensor option.
