This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ATE100X20SB — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ATE100X20SB in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB
The AirTAC Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB is a single acting, pull (spring return) DIN-standard tight/compact air cylinder with a Ø100mm bore and 20mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ATE100X20SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke20 mm
- Port size1/4"
- Acting typeSingle acting, pull (spring return)
- Rod threadM16×1.5
- StatusDiscontinued → ATE100X20SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB
A single acting pull cylinder with spring return, the ATP100X20SB keeps its 25 mm rod extended by an internal spring and retracts it with compressed air, delivering 3395.3 N of pull at 0.5 MPa (4867.9 N at 0.7 MPa), both figures already net of the spring. This 100 mm bore unit is discontinued, and the current-production ATE100X20 is the drop-in successor in the same bore, stroke and force class. Its short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which is why it fits dense press frames and guarded stations where a full-length body cannot.
For sizing, plan on roughly 2037 N of usable pull at 0.5 MPa instead of the full rating, which works out to lifting about 173 kg vertically with a 2:1 margin. The S code on this model means the optional -S magnet is fitted, so CMSE or DMSE reed and solid-state switches can be mounted for end-of-stroke signalling. The B code gives a male rod thread, the port is 1/4", and fixed TPU bumpers sit at both ends. Confirm the ISO 21287 mounting dimensions of the ATE100X20 before swapping.
Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB Technical Specifications
| Model | Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB |
|---|---|
| Series | ATP DIN compact cylinder (discontinued) |
| Replacement | ATE100X20SB |
| Bore size | Ø100 mm |
| Stroke | 20 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 25 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ATE100X20SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 3395.3 N |
| 0.7 MPa | 4867.9 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB
| ATP | DIN compact cylinder (single-acting pull, spring-return, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×20 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB Is Used
Spring-open clamp fixtures
On a CNC machining fixture, the spring holds the clamp open and 3395.3 N of air pull at 0.5 MPa retracts the hook into the clamped position, failing safe to open if air drops.
Pallet lift-and-lower check
The 20 mm stroke can lift about 173 kg vertically with a 2:1 margin at 0.5 MPa, enough to seat small pallets or chocks in packaging line fixtures.
Signalled gate retraction
Because this S-coded unit carries the optional -S magnet, a DMSE solid-state switch on the 100 mm bore body confirms retraction of an access gate before the next cycle starts.
Replacing the Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB with the ATE100X20SB
At 100 mm bore this is the strongest pull in the ATP range, so step down to the 80 mm bore (2159.1 N at 0.5 MPa) if your clamp load is marginal, and remember the spring needs at least 0.2 MPa of air pressure to retract. The 20 mm stroke sits well inside the short-stroke nature of single-acting pull designs, and speed runs 50-500 mm/s. On air loss the spring returns the rod to its extended home position; it does not hold a mid-stroke position, so add an external stop if you need intermediate holding. FA/FB flange, LB foot and CA/CB clevis mountings bolt to the standard face, and the ATE100X20 is the current replacement to quote.
Replacement checklist
- ✓ Current-production ACE → ATE100X20SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ATP Single Acting Port Compact Cylinder ATP100X20SB FAQ
It is a single-acting pull, spring-extend cylinder: the spring holds the rod out and air retracts it. Net pull is 3395.3 N at 0.5 MPa and 4867.9 N at 0.7 MPa, already after the spring. Operating pressure is 0.2-1.0 MPa (28-145 psi) with 0.2 MPa minimum to beat the spring, proof pressure 1.5 MPa (215 psi), air filtered to 40 um, temperature -20 to +70 C, speed 50-500 mm/s. Bore is 100 mm, stroke 20 mm, rod 25 mm, port 1/4", rod end male thread, and fixed TPU bumpers sit at both ends.
Order the ATE100X20, the current-production ISO 21287 successor made by swapping the P for an E. It matches the same 100 mm bore, 20 mm stroke and force class with a matching short body and mounting family, so the swap is close to drop-in. Because the ATP is DIN-standard, confirm the ISO 21287 mounting dimensions of the ATE before you commit, and carry over the -S magnet code if your CMSE or DMSE switches must keep working.
