This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ATE16X10B — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ATE16X10B in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ATP Single Acting Port Compact Cylinder ATP16X10B
The AirTAC Airtac ATP Single Acting Port Compact Cylinder ATP16X10B is a single acting, pull (spring return) DIN-standard tight/compact air cylinder with a Ø16mm bore and 10mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ATE16X10B (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ16 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeSingle acting, pull (spring return)
- Rod threadM4×0.7
- StatusDiscontinued → ATE16X10B
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATP Single Acting Port Compact Cylinder ATP16X10B
A single acting compact pull cylinder, the ATP16X10B uses an internal spring to extend the 8 mm rod while compressed air retracts it, delivering 53.3 N of pull at 0.5 MPa (83.5 N at 0.7 MPa, both net of the spring). The 16 mm bore needs at least 0.2 MPa to overcome the spring, and the short ISO 21287-class body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into tight fixtures a full-length body cannot reach.
Because the spring returns the rod to its extended home position on air loss, the ATP16X10B fails safe to extended but never holds a mid-stroke position. A fixed TPU bumper at each end decelerates travel, and the male rod thread (B code) bolts directly to standard I/Y knuckles. Note this model is discontinued: the current-production drop-in is the ATE16X10, so confirm ISO 21287 mounting dimensions before swapping. For a real-world margin, plan on roughly 32 N (about 3 kg) of usable pull at 0.5 MPa.
Airtac ATP Single Acting Port Compact Cylinder ATP16X10B Technical Specifications
| Model | Airtac ATP Single Acting Port Compact Cylinder ATP16X10B |
|---|---|
| Series | ATP DIN compact cylinder (discontinued) |
| Replacement | ATE16X10B |
| Bore size | Ø16 mm |
| Stroke | 10 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | M5×0.8 |
| Rod thread | M4×0.7 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 25 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ATE16X10B (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 53.3 N |
| 0.7 MPa | 83.5 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ATP Single Acting Port Compact Cylinder ATP16X10B
| ATP | DIN compact cylinder (single-acting pull, spring-return, discontinued). |
|---|---|
| 16 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ATP Single Acting Port Compact Cylinder ATP16X10B Is Used
Spring-up ejection from a drill fixture
The spring lifts a small aluminium bracket clear of a drilling jig the moment air pressure drops, with the 10 mm stroke and 53.3 N pull at 0.5 MPa enough for a part of about 2.7 kg with margin.
Retracting a light gate on a packaging line
Air pressure pulls a slim guard arm out of the product path at up to 500 mm/s, and the spring snaps it back to the extended safe position on any air loss.
Sample lift in a compact lab analyzer
The short body fits inside a benchtop diagnostic instrument where an ISO 15552 profile cylinder would be twice too long, raising a 2 kg sample tray vertically with the spring as the fail-safe.
Replacing the Airtac ATP Single Acting Port Compact Cylinder ATP16X10B with the ATE16X10B
Size the bore against your load: the 12 mm bore pulls only 25.9 N at 0.5 MPa, while stepping up to 20 mm gives 88.1 N, so the 16 mm bore at 53.3 N sits between them for light clamping or return tasks. If you need position holding mid-stroke, this spring-return pull design will not provide it - consider a double-acting ACP (now ACE) instead. The male rod thread suits knuckle-joint linkages; FA/FB flange, LB foot and CA/CB clevis mounts are available. Sensors need the optional -S magnet code (CMSE / DMSE switches); this non-S model has no magnet. Order the ATE16X10 as the current replacement.
Replacement checklist
- ✓ Current-production ACE → ATE16X10B
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ATP Single Acting Port Compact Cylinder ATP16X10B FAQ
This 16 mm bore, 10 mm stroke pull cylinder gives 53.3 N at 0.5 MPa and 83.5 N at 0.7 MPa, both already net of the return spring. Working pressure is 0.2-1.0 MPa (28-145 psi) with a 1.5 MPa (215 psi) proof rating, air filtered to 40 um, speed 50-500 mm/s, and temperature -20 to +70 C. The spring extends the rod; air retracts it. On air loss it returns to extended and does not hold a mid-stroke position.
No - the ATP family is discontinued. The current-production drop-in is the ATE16X10 (swap the P for an E), which matches the same bore, stroke and force class in the ISO 21287 short-body format. Confirm the ISO 21287 mounting dimensions against your fixture before swapping, since the ATP was built to a DIN-standard compact pattern. If you also need position sensing, order the -S magnet variant with CMSE or DMSE switches.
